12
groves. Built to last, the S2000 Micro
Sprinkler line incorporates a strong
bridge, built-in anti-insect device, and
a wear resistant design.
The S2000 Micro Sprinkler delivers
a consistent spray pattern at a low
angle, avoiding low hanging branches.
The sprinklers can be configured with
add-on features such as a spinner with
a range limiter, for a smaller wetting
diameter around young trees or a trunk
protector to keep the spray away from
the tree trunks.
The sprinklers can be installed on the
ground with a plastic stake or hung
from a wire. The S2000 FlowRegulated
Micro Sprinkler has the added feature
of flow regulation, extending the use
of the sprinklers to applications with
sloping fields and long lateral runs.
Features
Built-in anti-insect device
Wear resistant design
Israel
Metzerplas
Du-component PC
dripline
Single piece, dual component PC
dripper
PC labyrinth in a one-piece dripper
PC dripper for thin wall and medium
wall thickness driplines
Dripper flow rate: 1.0 l/h
Lateral diameter 12-22 mm
Lateral wall thickness 0.15-0.4 mm
(6-16 mil).
Spain
AZUD
State-of-the-art
technology, maximum
uniformity and
anti-siphon system
AZUD PREMIER PC AS is the flat
Pressure Compensating bond-on in
multi-seasonal driplines developed
by AZUD. Its design is based on
three key elements:
1. Anti-siphon system: It prevents the
introduction of contaminants inside
the emitter.
2. Maximum resistance to clogging:
the design of the labyrinth, with DS
Technology, and H.E.X. protection
system guarantee a high resistance
to clogging.
3. Higher pressure-compensating
range: thanks to the combination of
SILITECmembrane and the ELIPSIS
chamber.
The main application of this product
is the Sub-surface Drip Irrigation for
multiseasonal crops, but also it is
used for irrigation in intensive crops,
for tree exploitations and irrigation in
greenhouses.
